利用Python將圖片批量轉化成素描圖的過程記錄
發布日期：2022-02-14 10:32 | 文章來源：CSDN
正常圖片轉化成素描圖片無非對圖片像素的處理，矩陣變化而已。目前很多拍照修圖App都有這一功能，核心代碼不超30行。如下利用 Python 實現讀取一張圖片并將其轉化成素描圖片。至于批處理也簡單，循環讀取文件夾里的圖片處理即可。具體代碼可以去我的 GitHub 下載。
程序
Method 1
def plot_sketch(origin_picture, out_picture) :
a = np.asarray(Image.open(origin_picture).convert('L')).astype('float')
depth = 10. # (0-100)
grad = np.gradient(a) # 取圖像灰度的梯度值
grad_x, grad_y = grad # 分別取橫縱圖像梯度值
grad_x = grad_x * depth / 100.
grad_y = grad_y * depth / 100.
A = np.sqrt(grad_x ** 2 + grad_y ** 2 + 1.0)
uni_x = grad_x / A
uni_y = grad_y / A
uni_z = 1. / A
vec_el = np.pi / 2.2 # 光源的俯視角度，弧度值
vec_az = np.pi / 4. # 光源的方位角度，弧度值
dx = np.cos(vec_el) * np.cos(vec_az) # 光源對x 軸的影響
dy = np.cos(vec_el) * np.sin(vec_az) # 光源對y 軸的影響
dz = np.sin(vec_el) # 光源對z 軸的影響
b = 255 * (dx * uni_x + dy * uni_y + dz * uni_z) # 光源歸一化
b = b.clip(0, 255)
im = Image.fromarray(b.astype('uint8')) # 重構圖像
im.save(out_picture)
print("轉換成功，請查看 ： ", out_picture)
Method 2
def plot_sketch2(origin_picture, out_picture, alpha=1.0):
img = Image.open(origin_picture)
blur = 20
img1 = img.convert('L') # 圖片轉換成灰色
img2 = img1.copy()
img2 = ImageOps.invert(img2)
for i in range(blur): # 模糊度
img2 = img2.filter(ImageFilter.BLUR)
width, height = img1.size
for x in range(width):
for y in range(height):
a = img1.getpixel((x, y))
b = img2.getpixel((x, y))
img1.putpixel((x, y), min(int(a*255/(256-b*alpha)), 255))
img1.save(out_picture)
完整代碼
from PIL import Image, ImageFilter, ImageOps
import numpy as np
import os
def plot_sketch(origin_picture, out_picture) :
a = np.asarray(Image.open(origin_picture).convert('L')).astype('float')
depth = 10. # (0-100)
grad = np.gradient(a) # 取圖像灰度的梯度值
grad_x, grad_y = grad # 分別取橫縱圖像梯度值
grad_x = grad_x * depth / 100.
grad_y = grad_y * depth / 100.
A = np.sqrt(grad_x ** 2 + grad_y ** 2 + 1.0)
uni_x = grad_x / A
uni_y = grad_y / A
uni_z = 1. / A
vec_el = np.pi / 2.2 # 光源的俯視角度，弧度值
vec_az = np.pi / 4. # 光源的方位角度，弧度值
dx = np.cos(vec_el) * np.cos(vec_az) # 光源對x 軸的影響
dy = np.cos(vec_el) * np.sin(vec_az) # 光源對y 軸的影響
dz = np.sin(vec_el) # 光源對z 軸的影響
b = 255 * (dx * uni_x + dy * uni_y + dz * uni_z) # 光源歸一化
b = b.clip(0, 255)
im = Image.fromarray(b.astype('uint8')) # 重構圖像
im.save(out_picture)
print("轉換成功，請查看 ： ", out_picture)
def plot_sketch2(origin_picture, out_picture, alpha=1.0):
img = Image.open(origin_picture)
blur = 20
img1 = img.convert('L') # 圖片轉換成灰色
img2 = img1.copy()
img2 = ImageOps.invert(img2)
for i in range(blur): # 模糊度
img2 = img2.filter(ImageFilter.BLUR)
width, height = img1.size
for x in range(width):
for y in range(height):
a = img1.getpixel((x, y))
b = img2.getpixel((x, y))
img1.putpixel((x, y), min(int(a*255/(256-b*alpha)), 255))
img1.save(out_picture)
if __name__ == '__main__':
origin_picture = "pictures/5.jpg"
out_picture = "sketchs/sketch.jpg"
plot_sketch(origin_picture, out_picture)
origin_path = "./pictures"
out_path = "./sketchs"
dirs = os.listdir(origin_path)
for file in dirs:
origin_picture = origin_path + "/" + file
out_picture = out_path + "/" + "sketch_of_" + file
plot_sketch2(origin_picture, out_picture)
結果
總結
到此這篇關于利用Python將圖片批量轉化成素描圖的文章就介紹到這了,更多相關Python圖片批量轉素描圖內容請搜索本站以前的文章或繼續瀏覽下面的相關文章希望大家以后多多支持本站！
