python使用opencv切割圖片白邊
發布日期:2022-01-26 13:24 | 文章來源:CSDN
本文實例為大家分享了python使用opencv切割圖片白邊的具體代碼,可以橫切和豎切,供大家參考,具體內容如下
廢話不多說直接上碼,分享使人進步:
from PIL import Image
from itertools import groupby
import cv2
import datetime
import os
# from core.rabbitmq import MessageQueue
THRESHOLD_VALUE = 230 # 二值化時的閾值
PRETREATMENT_FILE = 'hq' # 橫切時臨時保存的文件夾
W = 540 # 最小寬度
H = 960 # 最小高度
class Pretreatment(object):
__doc__ = "圖片橫向切割"
def __init__(self, path, save_path, min_size=960):
self.x = 0
self.y = 0
self.img_section = []
self.continuity_position = []
self.path = path
self.save_path = save_path
self.img_obj = None
self.min_size = min_size
self.mkdir(self.save_path)
self.file_name = self.path.split('/')[-1]
def get_continuity_position_new(self):
img = cv2.imread(self.path)
gray_image = cv2.cvtColor(img, cv2.COLOR_BGR2GRAY)
ret, thresh1 = cv2.threshold(gray_image, THRESHOLD_VALUE, 255, cv2.THRESH_BINARY)
width = img.shape[1]
height = img.shape[0]
self.x = width
self.y = height
for i in range(0, height):
if thresh1[i].sum() != 255 * width:
self.continuity_position.append(i)
def filter_rule(self):
if self.y < self.min_size:
return True
def mkdir(self, path):
if not os.path.exists(path):
os.makedirs(path)
def get_section(self):
# 獲取區間
for k, g in groupby(enumerate(self.continuity_position), lambda x: x[1] - x[0]):
l1 = [j for i, j in g] # 連續數字的列表
if len(l1) > 1:
self.img_section.append([min(l1), max(l1)])
def split_img(self):
print(self.img_section)
for k, s in enumerate(self.img_section):
if s:
if not self.img_obj:
self.img_obj = Image.open(self.path)
if self.x < W:
return
if s[1] - s[0] < H:
return
cropped = self.img_obj.crop((0, s[0], self.x, s[1])) # (left, upper, right, lower)
self.mkdir(os.path.join(self.save_path, PRETREATMENT_FILE))
cropped.save(os.path.join(self.save_path, PRETREATMENT_FILE, f"hq_{k}_{self.file_name}"))
def remove_raw_data(self):
os.remove(self.path)
def main(self):
# v2
try:
self.get_continuity_position_new()
self.filter_rule()
self.get_section()
self.split_img()
except Exception as e:
print(self.file_name)
print(e)
finally:
if self.img_obj:
self.img_obj.close()
class Longitudinal(Pretreatment):
def get_continuity_position_new(self):
print(self.path)
img = cv2.imread(self.path)
gray_image = cv2.cvtColor(img, cv2.COLOR_BGR2GRAY)
ret, thresh1 = cv2.threshold(gray_image, THRESHOLD_VALUE, 255, cv2.THRESH_BINARY)
width = img.shape[1]
height = img.shape[0]
print(width, height)
self.x = width
self.y = height
for i in range(0, width):
if thresh1[:, i].sum() != 255 * height:
self.continuity_position.append(i)
def split_img(self):
print(self.img_section)
for k, s in enumerate(self.img_section):
if s:
if not self.img_obj:
self.img_obj = Image.open(self.path)
if self.y < H:
return
if s[1] - s[0] < W:
return
cropped = self.img_obj.crop((s[0], 0, s[1], self.y)) # (left, upper, right, lower)
cropped.save(os.path.join(self.save_path, f"{k}_{self.file_name}"))
def main(path, save_path):
starttime = datetime.datetime.now()
a = Pretreatment(path=path, save_path=save_path)
a.main()
for root, dirs, files in os.walk(os.path.join(save_path, PRETREATMENT_FILE)):
for i in files:
b = Longitudinal(path=os.path.join(save_path, PRETREATMENT_FILE, i), save_path=save_path)
b.main()
os.remove(os.path.join(save_path, PRETREATMENT_FILE, i))
endtime = datetime.datetime.now()
print(f'耗時:{(endtime - starttime)}')
if __name__ == '__main__':
path = '你圖片存放的路徑'
save_path = '要保存的路徑'
for _, _, files in os.walk(path):
for i in files:
main(path=os.path.join(path, i), save_path=save_path)
os.rmdir(os.path.join(save_path, PRETREATMENT_FILE))
原始圖片:

結果:


以上就是本文的全部內容,希望對大家的學習有所幫助,也希望大家多多支持本站。
